ENGLISH SPECIFICATION
Radio Controlled Room Thermostat Receiver Module for: see list page 3
Supply Voltage 230 Vac ± 15%, 50Hz
Construction BS EN 60730-2-1, EN 300-220-1
Maximum Ambient Temperature 45°C
Switch Type RX1 - 1 x SPDT, type 1B
RX2 - 1 x SPDT, 1 x SPST, type 1B
RX3 - 1 x SPDT, 2 x SPST, type 1B
Switch Rating 264 Vac, 3 (1) A (Total current)
IP Rating IP 40
Control Pollution Situation Degree 2
Max. Range 30 metres
Operating Frequency 433.92 MHz
Software Classi cation Class A
Rated Impulse Voltage 2.5kV
Ball Pressure Test 75°C
