CB70 and BT06K specifications
CB70 battery charger
Specification Value
Standard AC power supply 230 Vca ± 10%, 50
Optional AC power supply 115 Vca, 60 Hz
DC power supply From 10.5 V to 35V
BT06K battery
Specification Value
Voltage 4.8 V
Capacity 600 mAh NiMH
Charging temperature From 0° to 45° C
Discharge temperature From -20° to 50° C
Autonomy 10 h (use at 50%)
Charging mode Fast (<2h) and intelligent
Weight 70.3 g
The battery is protected by an internal fuse.
Setting up the CB70 battery charger
Use the information below to properly set up the CB70 batter charger.
The battery charger has two charging compartments that can simultaneously charge two batteries.
1. Connect the charger to a power source using the cable supplied.
The red LED will switch.
User Manual
T70 1 Transmitter
Charger and battery
10 |
©
Danfoss | March 2019 BC300870271580en-000101
