Danfoss VLT 5000 Series Operating Instructions

VLT
®
5000 Series
PNU Parameter Factory setting Range Changes 4-Setup Conversion Data
# description during operation index type
200 Output frequency
range/direction
Only clockwise, 0-132 Hz No Yes 0 5
201 Output frequency low limit 0.0 Hz 0.0 - f
MAX
Yes Yes -1 6
202 Output frequency high limit 66 / 132 Hz f
MIN
- par. 200 Yes Yes -1 6
203 Reference/feedback area Min - max Yes Yes 0 5
204 Minimum reference 0.000 -100,000.000-Ref
MAX
Yes Yes -3 4
205 Maximum reference 50.000 Ref
MIN
-100,000.000 Yes Yes -3 4
206 Ramp type Linear Yes Yes 0 5
207 Ramp-up time 1 Depends on unit 0.05 - 3600 Yes Yes -2 7
208 Ramp-down time 1 Depends on unit 0.05 - 3600 Yes Yes -2 7
209 Ramp-up time 2 Depends on unit 0.05 - 3600 Yes Yes -2 7
210 Ramp-down time 2 Depends on unit 0.05 - 3600 Yes Yes -2 7
211 Jog ramp time Depends on unit 0.05 - 3600 Yes Yes -2 7
212 Quick stop ramp-down time Depends on unit 0.05 - 3600 Yes Yes -2 7
213 Jog frequency 10.0 Hz 0.0 - par. 202 Yes Yes -1 6
214 Reference function Sum Yes Yes 0 5
215 Preset reference 1 0.00 % - 100.00 - 100.00 % Yes Yes -2 3
216 Preset reference 2 0.00 % - 100.00 - 100.00 % Yes Yes -2 3
217 Preset reference 3 0.00 % - 100.00 - 100.00 % Yes Yes -2 3
218 Preset reference 4 0.00 % - 100.00 - 100.00 % Yes Yes -2 3
219 Catch up/slow down value 0.00 % 0.00 - 100 % Yes Yes -2 6
220
221 Torque limit for motor mode 160 % 0.0 % - xxx % Yes Yes -1 6
222 Torque limit for regenerative
operation
160 % 0.0 % - xxx % Yes Yes -1 6
223 Warning: Low current 0.0 A 0.0 - par. 224 Yes Yes -1 6
224 Warning: High current I
VLT,MAX
Par. 223 - I
VLT,MAX
Yes Yes -1 6
225 Warning: Low frequency 0.0 Hz 0.0 - par. 226 Yes Yes -1 6
226 Warning: High frequency 132.0 Hz Par. 225 - par. 202 Yes Yes -1 6
227 Warning: Low feedback -4000.000 -100,000.000 - par. 228 Yes -3 4
228 Warning: High feedback 4000.000 Par. 227 - 100,000.000 Yes -3 4
229 Frequency bypass, bandwidth OFF 0 - 100 % Yes Yes 0 6
230 Frequency bypass 1 0.0 Hz 0.0 - par. 200 Yes Yes -1 6
231 Frequency bypass 2 0.0 Hz 0.0 - par. 200 Yes Yes -1 6
232 Frequency bypass 3 0.0 Hz 0.0 - par. 200 Yes Yes -1 6
233 Frequency bypass 4 0.0 Hz 0.0 - par. 200 Yes Yes -1 6
234 Motor phase monitor Enable Yes Yes 0 5
MG.51.A9.02 - VLT is a registered Danfoss trademark
180
