Danfoss VLT 5000 Series Operating Instructions

VLT
®
5000 Series
PNU Parameter Factory setting Range Changes 4-Setup Conversion Data
# description during operation index type
400 Brake function/overvoltage control Off Yes No 0 5
401 Brake resistor, ohm Depends on the unit Yes No -1 6
402 Brake power limit, kW Depends on the unit Yes No 2 6
403 Power monitoring On Yes No 0 5
404 Brake check Off Yes No 0 5
405 Reset function Manual reset Yes Yes 0 5
406 Automatic restart time 5 sec. 0 - 10 sec. Yes Yes 0 5
407 Mains Failure No function Yes Yes 0 5
408 Quick discharge Not possible Yes Yes 0 5
409 Trip delay torque Off 0 - 60 sec. Yes Yes 0 5
410 Trip delay-inverter Depends on type of unit 0 - 35 sec. Yes Yes 0 5
411 Switching frequency Depends on type of unit 1.5 - 14 kHz Yes Yes 2 6
412 Output frequency dependent switching
frequency
Not possible Yes Yes 0 5
413 Overmodulation function On Yes Yes -1 5
414 Minimum feedback 0.000 -100,000.000
-FB
HIGH
Yes Yes -3 4
415 Maximum feedback 1500.000 FB
LOW
-
100,000.000
Yes Yes -3 4
416 Process unit %YesYes05
417 Speed PID proportional gain 0.015 0.000 - 0.150 Yes Yes -3 6
418 Speed PID integration time 8 ms 2.00 - 999.99
ms
Yes Yes -4 7
419 Speed PID differentiation time 30 ms 0.00 - 200.00
ms
Yes Yes -4 6
420 Speed PID diff. gain ratio 5.0 5.0 - 50.0 Yes Yes -1 6
421 Speed PID low-pass filter 10ms 5-200ms Yes Yes -4 6
422 U0voltageat0Hz 20.0 V 0.0 -
parameter
103
Yes Yes -1 6
423 U1voltage parameter 103 0.0 - U
VLT, MAX
Yes Yes -1 6
424 F 1 frequency parameter 104 0.0 -
parameter
426
Yes Yes -1 6
425 U2voltage parameter 103 0.0 - U
VLT, MAX
Yes Yes -1 6
426 F 2 frequency parameter 104 par.424-
par.428
Yes Yes -1 6
427 U3voltage parameter 103 0.0 - U
VLT, MAX
Yes Yes -1 6
428 F 3 frequency parameter 104 par.426
-par.430
Yes Yes -1 6
429 U4voltage parameter 103 0.0 - U
VLT, MAX
Yes Yes -1 6
MG.51.A9.02 - VLT is a registered Danfoss trademark
182
