Danfoss VLT 5000 Series Operating Instructions

VLT
®
5000 Series
PNU Parameter Factory setting Range Changes 4-Setup Conversion Data
# description during operation index type
500 Address 1 0 - 126 Yes No 0 6
501 Baudrate 9600 Baud Yes No 0 5
502 Coasting Logic or Yes Yes 0 5
503 Quick-stop Logic or Yes Yes 0 5
504 DC-brake Logic or Yes Yes 0 5
505 Start Logic or Yes Yes 0 5
506 Reversing Logic or Yes Yes 0 5
507 Selection of setup Logic or Yes Yes 0 5
508 Selection of speed Logic or Yes Yes 0 5
509 Bus jog 1 10.0 Hz 0.0 - parameter 202 Yes Yes -1 6
510 Bus jog 2 10.0 Hz 0.0 - parameter 202 Yes Yes -1 6
511
512 Telegram profile FC Drive No Yes 0 5
513 Bus time interval 1 sec. 1 - 99 s Yes Yes 0 5
514 Bus time interval function Off Yes Yes 0 5
515 Data read-out: Reference % No No -1 3
516 Data read-out: Reference unit No No -3 4
517 Data read-out: Feedback No No -3 4
518 Data read-out: Frequency No No -1 6
519 Data read-out: Frequency x Scaling No No -2 7
520 Data read-out: Current No No -2 7
521 Data read-out: Torque No No -1 3
522 Data read-out: Power, kW No No 1 7
523 Data read-out: Power, HP No No -2 7
524 Data read-out: Motor voltage No No -1 6
525 Data read-out: DC link voltage No No 0 6
526 Data read-out: Motor temp. No No 0 5
527 Data read-out: VLT temp. No No 0 5
528 Data read-out: Digital input No No 0 5
529 Data read-out: Terminal 53,
analogue input
No No -2 3
530 Data read-out: Terminal 54,
analogue input
No No -2 3
531 Data read-out: Terminal 60,
analogue input
No No -5 3
532 Data read-out: Pulse reference No No -1 7
533 Data read-out: External reference % No No -1 3
534 Data read-out: Status word, binary No No 0 6
535 Data read-out: Brake power/2 min. No No 2 6
536 Data read-out: Brake power/sec. No No 2 6
537 Data read-out: Heat sink temperature No No 0 5
538 Data read-out: Alarm word, binary No No 0 7
539 Data read-out: VLT Control word, binary No No 0 6
540 Data read-out: Warning word, 1 No No 0 7
541 Data read-out: Extended Status word No No 0 7
553 Display text 1 No No 0 9
554 Display text 2 No No 0 9
557 Data read-out: Motor RPM No No 0 4
558 Data read-out: Motor RPM x scaling No No -2 4
580 Defined parameter No No 0 6
581 Defined parameter No No 0 6
582 Defined parameter No No 0 6
MG.51.A9.02 - VLT is a registered Danfoss trademark
184
