Danfoss VLT 5000 Series Design Guide

Immunity continued
Basic specifications Burst
IEC 61000-4-4
Surge
IEC 61000-4-5
ESD
IEC 61000-4-2
Radiated electromagnetic field
IEC 61000-4-3
Mains
distortion
VDE 0160
RF common
mode voltage
IEC 61000-4-6
Line 4kV/5 kHz/DCN 2 kV/2Ω 4 kV/12Ω
2,3 x U
N
2)
10 V
RMS
Motor 4kV/5 kHz/CCC 10 V
RMS
Control lines 2kV/5 kHz/CCC
2 kV/2Ω
1)
10 V
RMS
Application and Fieldbus options 2kV/5 kHz/CCC
2 kV/2Ω
1)
10 V
RMS
Signal interface <3 m
1kV/5 kHz/CCC 10 V
RMS
Enclosure 8 kV AD
6 kV CD
10 V/m
Load sharing 4kV/5 kHz/CCC 10 V
RMS
Standard bus 2kV/5 kHz/CCC
– 4 kV/2Ω
1)
10 V
RMS
Brake 4kV/5 kHz/CCC 10 V
RMS
External 24 V DC 2kV/5 kHz/CCC
– 4 kV/2Ω
1)
10 V
RMS
DM: Differential mode CM: Common mode CCC: Capacitive clamp coupling DCN: Direct coupling network
1. Injection on cable shield. 2. 2,3 x U
N
: max. test pulse 380 V
AC
: Class 2/1250 V
PEAK
, 415 V
AC
: Class 1/1350 V
PEAK
VLT
®
5000 Design Guide
MG.52.B2.02 - VLT
®
is a registered Danfoss trademark 127
