VLT
®
5000 SyncPos option
MG.10.J4.02 – VLT is a registered Danfoss trade mark
156
Messages and Error Reference
■■
■■
■ VLT and SyncPos option messages
All messages are shown in the LCP display of the
VLT in short and in the SyncPos software in plain
text.
You can find brief information on the error
messages in the table or detailed information in
the following section.
■■
■■
■ Table of Messages
The tables contain the messages in numerical
order. Letters following a % sign represent
variables which can be used in plain text at the
corresponding locations.
O.ERR_ LCP-Display SyncPos message
3 AXES NOT IN SYSTEM Axis no. %bu not in system
5 ERROR NOT CLEARED Axis no: 1 Error not cleared
6 HOME NOT EXECUTED Axis no: 1 Failed to move to HOME position
7 HOME_VEL ZERO Axis no: 1 Home vel 0
8 POSITION ERROR Axis no: 1 Position error
9 INDEX NOT FOUND Axis no: 1 Index pulse (encoder) not found
10 UNKNOWN COMMAND Unknown command
11 SOFTWARE LIMIT ACT. Axis no.1 Software limit switch activated
12 ILLEGAL PARAMET. NO Illegal parameter number
13 General VLT error General VLT error
14 TOO MANY NEST. LOOP Too many nested loops
16 PARAM. ERROR EEPROM Parameters in EEPROM are corrupted
17 PROGR. ERROR EEPROM Programs in EEPROM are corrupted
18 RESET BY CPU Reset by CPU
19 USER ABORT User abort
25 LIMIT SWITCH ACTIV. Axis no. 1 Limit switch activated
51 TOO MANY NEST. GOSUB Too many nested GOSUB commands
52 TOO MANY RETURN Too many RETURN commands
62 ERROR IN VERIFYING EEPROM: address % defect
70 ERROR IN DIM COMMD Error in DIM command
71 ARRAYBOUNDS CROSSED Attempt was made to cross arraybounds
79 TIMEOUT WAITNDX Timeout while waiting for index
84 TOO MANY ONTIME Too many time interrupts
87 OUT OF MEMORY (VAR) No more room for variables
90 MEMORY locked The program memory is write-protected.
xx INTERNAL ERROR Internal error ##
