Danfoss VLT FC 300

Par.
No. #
Parameter description Default value 4-set-up FC 302
only
Change
during
operation
Conver-
sion
index
Type
6-7* Analog Output 3
6-70 Terminal X45/1 Output null All set-ups TRUE - Uint8
6-71 Terminal X45/1 Min. Scale 0.00 % All set-ups TRUE -2 Int16
6-72 Terminal X45/1 Max. Scale 100.00 % All set-ups TRUE -2 Int16
6-73 Terminal X45/1 Bus Control 0.00 % All set-ups TRUE -2 N2
6-74 Terminal X45/1 Output Timeout Preset 0.00 % 1 set-up TRUE -2 Uint16
6-8* Analog Output 4
6-80 Terminal X45/3 Output null All set-ups TRUE - Uint8
6-81 Terminal X45/3 Min. Scale 0.00 % All set-ups TRUE -2 Int16
6-82 Terminal X45/3 Max. Scale 100.00 % All set-ups TRUE -2 Int16
6-83 Terminal X45/3 Bus Control 0.00 % All set-ups TRUE -2 N2
6-84 Terminal X45/3 Output Timeout Preset 0.00 % 1 set-up TRUE -2 Uint16
How to Programme
VLT
®
Automation Drive FC 300 12-Pulse
Operating Instructions High Power
MG34Q202 - VLT
®
is a registered Danfoss trademark 71
4 4
