Surroundings
Enclosure IP21/Type 1, IP54/Type 12
Vibration test 0.7 g
Max. relative humidity 5%-95%(IEC 721-3-3; Class 3K3 (non-condensing) during operation
Aggressive environment (IEC 60068-2-43
class H
2
5
Ambient temperature (with SFAVM switching mode)
- with derating Max. 55° C
1)
- at full continuous drive output current Max. 45° C
1)
1) For more information on derating, see special conditions in the VLT AutomationDrive Design Guide, MG33BXYY
Minimum ambient temperature during full-scale operation 0° C
Minimum ambient temperature at reduced performance - 10° C
Temperature during storage/transport -25 - +65/70° C
Maximum altitude above sea level without derating 1000 m
Derating for high altitude, see special conditions in the VLT AutomationDrive Design Guide, MG33BXYY
EMC standards, Emission EN 61800-3, EN 61000-6-3/4, EN 55011
EMC standards, Immunity
EN 61800-3, EN 61000-6-1/2,
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6
See section on special conditions in the VLT AutomationDrive Design Guide, MG33BXYY.
Protection and Features
•
Electronic thermal motor protection against overload.
•
Temperature monitoring of the heatsink ensures that the frequency converter trips if the temperature reaches a
predefined level. An overload temperature cannot be reset until the temperature of the heatsink is below the
values stated in the tables on the following pages (Guideline - these temperatures may vary for different power
sizes, frame sizes, enclosure ratings etc.).
•
The frequency converter is protected against short-circuits on motor terminals U, V, W.
•
If a mains phase is missing, the frequency converter trips or issues a warning (depending on the load).
•
Monitoring of the intermediate circuit voltage ensures that the frequency converter trips if the intermediate circuit
voltage is too low or too high.
•
The frequency converter constantly checks for critical levels of internal temperature, load current, high voltage on
the intermediate circuit and low motor speeds. As a response to a critical level, the frequency converter can adjust
the switching frequency and/ or change the switching pattern in order to ensure the performance of the
frequency converter.
General Specifications
VLT
®
Automation Drive FC 300 12-Pulse
Operating Instructions High Power
98 MG34Q202 - VLT
®
is a registered Danfoss trademark
55
