Danfoss VLT FCD 330 Design Guide

VLT
®
FCD Series
621-642 Nameplate
Value:
Par.
no
Description
Nameplate
Display text
621 Unit type (DRIVE TYPE)
624 Software version (SOFTWARE VERSION)
625 LCP identification no. (LCP VERSION)
626 Database identification no. (DATABASE VER.)
627 Power parts version (POWER UNIT DB ID)
628 Application option type (APP. OPTION)
630 Communication option type (COM. OPTION)
632 BMC software identification (BMC-SOFTWARE ID)
634 Unit identification for communication (UNIT ID)
635 Software parts no. (SW. PART NO.)
640 Software version (SOFTWARE VERSION)
641 BMC-software identification (BMC2 SW)
642 Power card identification (POWER ID)
Function:
The unit’s main data can be read out from parame-
ters 621 to 635 Nameplate using the LCP control
unit or serial communication. Parameters 640 - 642
can also be seen on the unit’s integral display.
Description of choice:
Parameter 621 Nameplate: Unit type:
Gives unit size and mains voltage.
Example: FCD 311 380-480 V.
Parameter 624 Nameplate: Software version no.
The unit’s present software version number appears
here.
Example: V 1.00
Parameter 625 Nameplate: LCP ID number:
The ID number of the unit’s LCP appears here.
Example: ID 1.42 2 kB
Parameter 626 Nameplate: Database ID number:
The ID number of the software’s database appears
here.
Example: ID 1.14.
Parameter 627 Nameplate: Power section version:
The ID number of the unit’s power section appears
here.
Example: ID 1.15.
Parameter 628 Nameplate: Application option type:
Here you can see which types of application options
are installed in the frequency converter.
Parameter 630 Nameplate: Communication option
type:
Here you can see which types of communication op-
tions are installed in the frequency converter.
Parameter 632 Nameplate: BMC software identifica-
tion:
The ID number of the BMC software appears here.
Parameter 634 Nameplate: Unit identification for
communication:
The ID number for communication appears here.
Parameter 635 Nameplate: Software section no.:
The software section number appears here.
Parameter 640 Nameplate: Software version:
The unit’s present software version number appears
here. Example: 1.00
Parameter 641 Nameplate: BMC software identifica-
tion:
The ID number of the BMC software appears here.
Parameter 642 Nameplate: Power card identification:
The ID number of the unit’s power part appears
here. Example: 1.15
678
678 Configure Control Card
(CONFIG CONTROL CARD)
Value:
✭Standard version (STANDARD VERSION)
[1]
Profibus 3 Mbaud Version
(PROFIBUS 3 BS VER.)
[2]
Profibus 12 Mbaud Version
(PROFIBUS 12 MB VER.)
[3]
✭
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.04.A1.02 - VLT is a registered Danfoss trade mark
116
