Danfoss VLT FCD 330 Design Guide

VLT
®
FCD Series
Control card, analog output:
Number of programmable analog outputs ........................................................................................................... 1
Terminal number ................................................................................................................................................ 42
Current range at analog output .......................................................................................................... 0/4 - 20 mA
Max. load to common at analog output ...................................................................................................... 500

Accuracy on analog output ................................................................................... Max. error: 1.5 % of full scale
Resolution on analog output ........................................................................................................................ 10 bit
The analog output is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
See section entitled Galvanic Isolation.
Control card, 24 V DC output:
Terminal number ................................................................................................................................................ 12
Max. load .................................................................................................................................................. 130 mA
The 24 V DC supply is galvanically isolated from the supply voltage (PELV) , but has the same potential as the
analogue and digital inputs and outputs. See section entitled Galvanic Isolation.
Control card, 10 V DC output:
Terminal number ................................................................................................................................................ 50
Output voltage ................................................................................................................................. 10.5 V ±0.5 V
Max. load .................................................................................................................................................... 15 mA
The 10 V DC supply is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
See section entitled Galvanic Isolation.
Control card, RS 485 serial communication:
Terminal number .................................................................................................... 68 (TX+, RX+), 69 (TX-, RX-)
Terminal number 67 ...................................................................................................................................... + 5 V
Terminal number 70 .................................................................................. Common for terminals 67, 68 and 69
Full galvanic isolation. See section entitled Galvanic Isolation.
Relay outputs:
Number of programmable relay outputs .............................................................................................................. 1
Terminal number, control card ......................................................................................... 1-3 (break), 1-2 (make)
Max. terminal load (AC) on 1-3, 1-2, control card ........................................................................ 240 V AC, 2 A
Min. terminal load on 1-3, 1-2, control card .................................................. 24 V DC 10 mA, 24 V AC 100 mA
The relay contact is separated from the rest of the circuit by strengthened isolation. See section entitled Gal-
vanic Isolation.
External 24 Volt DC supply:
Terminal nos ................................................................................................................................................ 35, 36
Voltage range .............................................................................................. 20-30 V (max. 37 V DC for 10 sec.)
Max. voltage ripple .................................................................................................................................... 2 V DC
Power consumption with/without mains supply ................................................................................. 0.1W/5-12W
Reliable galvanic isolation: Full galvanic isolation if the external 24 V DC supply is also of the PELV type.
Cable lengths and cross sections:
Max. motor cable length, screened/armoured cable .................................................................................... 10 m
Max. motor cable length, unscreened/unarmoured cable ............................................................................ 10 m
Max. cross section to motor, see next section.
Max. cross section to control wires, rigid wire .......................................................................... 4.0 mm
2
/10 AWG
Max. cross section to control cables, flexible cable .................................................................. 2.5 mm
2
/12 AWG
Max. cross section to control cables, cable with ferrules ......................................................... 2.5 mm
2
/12 AWG
MG.04.A1.02 - VLT is a registered Danfoss trade mark
132
