VLT
®
FCM Series
All about FCM
300
Functions to programme, to control, and to monitor via bus (PROFIBUS) or by PC.
Parameter
No. Function
Range/number of
settings/value Factory setting
Data
type
Conv.
index
400 Brake function Off/AC braking Off 5 0
403 Sleep mode timer 0-300 sec. Off 6 0
404 Sleep frequency f
MIN
-par407 0Hz 6 -1
405 Reset function 11 Manual reset 5 0
406 Boost setpoint 1-200 % 100 % 6 0
407 Wake up frequency Par 404 - f
MAX
50 Hz 6 -1
411 Switching frequency 1.5 - 14.0 kHz Unit dependent 6 0
412 Variable switching frequency 3 Temp. dep. sw. freq. 5 0
413 Overmodulation function Off/On On 5 0
414 Minimum feedback -100000 - FB
HIGH
04-3
415 Maximum feedback FB
LOW
- 100,000 1500 4 -3
416 Reference/feedback unit 42 % 5 0
437 Process PID normal/inverse ctrl. Normal/inverse Normal 5 0
438 Process PID anti windup Disable/Enable Enable 5 0
439 Process PID start frequency f
MIN
-f
MAX
f
MIN
6-1
440 Process PID proportional gain 0.00 (off) - 10.00 0.01 6 -2
441 Process PID integral time 0.01 - 9999 sec. (off) 9999 sec. 7 -2
442 Process PID differentation time 0.00 (off) - 10.00 sec. 0.00 sec. 6 -2
443 Process PID different. gain limit 5 -50 5 6 -1
444 Process PID lowpass filter time 0.1 - 10.00 sec. 0.1 sec. 6 -2
445 Flying start 4 Disable 5 0
446 Switching pattern 2 SFAVM 5 0
461 Feedback conversion Linear or square root Linear 5 0
Conversion index:
This number refers to a conversion figure to be used
when writing or reading via serial communication
with a frequency converter.
See Databytes in Serial Bus.
D
ata type:
Data type shows the type and length of the telegram.
Data type Description
3 Integer 16
4 Integer 32
5Unsigned8
6Unsigned16
7Unsigned32
9Textstring
MG.03.H3.02 - VLT is a registered Danfoss trademark
