Danfoss VLT FCM Series User Manual

VLT
®
FCM Series
Functions to programme, to control, and to monitor via bus (PROFIBUS) or by PC.
Parame-
ter No. Function
Range/number of
settings/value Factory setting
Data
type
Conv.
index
500 Bus address 1 - 126 1 5 0
501 Baudrate 300 - 9600 Baud/6 9600 Baud 5 0
502 Coasting 4 Logic or 5 0
503 Quick-stop 4 Logic or 5 0
504 DC-brake 4 Logic or 5 0
505 Start 4 Logic or 5 0
506 Reversing 4 Logic or 5 0
507 Selection of setup 4 Logic or 5 0
508 Selection of speed 4 Logic or 5 0
509 Bus jog 1 0.0 - f
MAX
10.0 Hz 6 -1
510 Bus jog 2 0.0 - f
MAX
10.0 Hz 6 -1
512 Telegram profile Profidrive/FC Drive FC Drive 5 0
513 Bus time interval 1 sec. 5 0
514 Bus time interval function 6 Off 5 0
515 Data read-out: Reference XXX.X 3 -1
516 Data read-out: Refer. unit Hz/rpm 4 -3
517 Data read-out: Feedback 4-3
518 Data read-out: Frequency Hz 3 -1
519 Data read-out: Frequency x scale Hz 7 -2
520 Data read-out: Current A x 100 7 -2
521 Data read-out: Torque % 3 -1
522 Data read-out: Power kW 7 1
523 Data read-out: Power hp 7 -2
524 Data read-out: Motor voltage V 6 -1
525 Data read-out: DC link voltage V 6 0
527 Data read-out: FC therm. 0 - 100 % 5 0
528 Data read-out: Digital input 50
533 Data read-out: External reference -200.0 - +200.0 % 6 -1
534 Data read-out: Status word, binary 6 0
537 Data read-out: FC temperature °C 5 0
538 Data read-out: Alarm word, binary 7 0
539 Data read-out: Control word, binary 6 0
540 Data read-out: Warning word, 1 7 0
541 Data read-out: Warning word, 2 7 0
542 Data read-out: Terminal 1, analog input mA X 10 5 -4
543 Data read-out: Terminal 2, analog input V X 10 5 -1
MG.03.H3.02 - VLT is a registered Danfoss trademark
102
