VLT
®
FCM Series
Programming
200 Rotation direction
(ROTATION)
Value:
✭Only clockwise,
(ONLY CLOCKWISE)
[0]
Both directions,
0-132 Hz (132 HZ BOTH DIRECTIONS)
[1]
Only counterclockwise, 0-132 Hz
(132HZ COUNTERCLOCKW.)
[2]
Function:
This parameter guarantees protection against
unwanted reversing.
Using Process, closed loop mode (parameter
100) parameter 200 must n
ot be changed
to Both directions [1].
Description of choice:
Select the desired direction seen from the
motor drive end.
Note that if Only clockwise, 0-132 Hz [0] /Only
counterclockwise, 0-132 Hz [2] is selected, the output
frequency will be limited to the range f
MIN
-f
MAX
.
If Both direct ions, 0-132 Hz [1] is selected, the output
frequency will be limited to the range ± f
MAX
(the
minimum frequency is of no significance).
NB!:
This is only possible in Stop Mode (motor
stopped on a Stop command). Ramp will
be followed, if no set up change.
NB!:
If parameter 200, selection of direction, is set
for different values in the 2 setups, and the
setup is changed during operation, the direction
changes without ramping. In such cases trip may
occur and that may reduce the service life of the power
module, as well as it may be harmful to the application.
Therefore!
It is recommended n
ot to set parameter 200 for
different values in the 2 setups. If that should be
necessary the user must make sure that setup
changes are only made with stopped motor.
201 Min. output frequency
(MIN OUTPUT FREQ)
Value:
0.0 HZ - f
MAX
(PARAMETER 202)
[0 -]
✭0.0 HZ
[0]
Function:
In this parameter, a minimum motor frequency limit
can be selected that corresponds to the minimum
frequency at which the motor is to run.
The minimum frequency can never be higher than
the maximum frequency, f
MAX
.
If Both directions has been selected in parameter 200,
the minimum frequency is of no significance.
Description of choice:
A value from 0.0 Hz to the max. frequency selected
in parameter 202 (f
MAX
) can be chosen.
202 Max. output frequency
(MAX OUTPUT FREQ)
Value:
f
MIN
(parameter 201) - f
RANGE
(132 Hz, par. 200)
✭f
RANGE
Function:
In this parameter, a maximum motor frequency
can be selected that corresponds to the highest
frequency at which the motor is to run.
See also parameter 205.
Description of choice:
Avaluefromf
MIN
to 132 Hz can be selected.
203 Reference/feedback range
(REF/FEEDB. RANGE)
Value:
✭Min - Max (MIN - MAX)
[0]
-Max-+Max(-MAX-+MAX)
[1]
Function:
This parameter decides whether the reference signal is
to be positive or can be both positive and negative.
NB!:
Analogue input (reference/feedback) can
only be positive.
Choose Min - Max [0] if Proces s, closed loop mode
has been selected in parameter 100.
Description of choice:
Choose the desired range.
✭ = factory setting. () = display text [] = value for use in communication via serial communication port
MG.03.H3.02 - VLT is a registered Danfoss trademark
45
