Function:
This parameter determines the value of the reference
signal that is to correspond to the minimum
reference value set in parameter 204.
If the Time-out function of parameter 317 is to be
used, the setting must be > 2 mA.
Description of choice:
Set the desired current value.
337 Terminal 1, max. scaling
(AI 1 SCALE HIGH)
Value:
0.0 - 20.0 mA
[0 - 200]
✭20.0 mA
[200]
Function:
This parameter sets the value of the reference
signal that is to correspond to the maximum
reference value set in parameter 205.
Description of choice:
Set the desired current value.
338 Terminal 2, min. scaling
(AI 2 SCALE LOW)
Value:
0.0 - 10.0 V
[0 - 100]
✭0.0 V
[0]
Function:
This parameter is used for setting the signal value
that is to correspond to the minimum reference or
the minimum feedback, parameter 204 Minimum
reference, Ref
MIN
/ 414 Minimum feedback, FB
MIN
.
Description of choice:
Set the required voltage value. For reasons of accuracy,
compensation should be made for voltage loss in long
signal cables. If the Time out function is to be used
(parameter 317 Time out and 318 Function after time
out), the value set must be higher than 1 Volt.
339 Terminal 2, max. scaling
(AI 2 SCALE HIGH)
Value:
0.0 - 10.0 V0.0 - 10.0 V
[0 - 100]
✭10.0 V
[100]
Function:
This parameter is used for setting the signal value
that is to correspond to the maximum reference value
or maximum feedback, parameter 205 Maximum
reference, Ref
MAX
/ 415 Maximum feedback, FB
MAX
.
Description of choice:
Set the required voltage value. For reasons of
accuracy, compensation should be made for
voltage losses in long signal cables.
✭ = factory setting. () = display text [] = value for use in communication via serial communication port
MG.03.H3.02 - VLT is a registered Danfoss trademark
56
