VLT
®
FCM Series
Programming
340 Terminal 9, output functions (OUTPUT FUNC.)
Settings:
✭No function (NO OPERATION) [0]
Ready signal (UNIT READY) [1]
Enable, no warning (ENABLE/NO WARNING) [2]
Running (MOTOR RUNNING) [3]
Running, no warning (RUNNING NO WARNING) [4]
Running on reference, no warning (RUNNING ON REFERENCE) [5]
Fault (FAULT) [6]
Fault or warning (FAULT OR WARNING) [7]
Current limit (CURRENT LIMIT) [8]
Thermal warning (THERMAL WARNING) [9]
Reversing (REVERSE) [10]
Control word bit 11 (CONTROL WORD BIT 11) [11]
Actual frequency 0-20 mA (0-FMAX = 0-20 mA) [12]
Actual frequency 4-20 mA (0-FMAX = 4-20 mA) [13]
Reference
MIN
- reference
MAX
: 0-20 mA (REF MIN-MAX =0-20 mA) [14]
Reference
MIN
- reference
MAX
: 4-20 mA (REF MIN-MAX =4-20 mA) [15]
Feedback
MIN
- feedback
MAX
: 0-20 mA (FB MIN-MAX =0-20 mA) [16]
Feedback
MIN
- feedback
MAX
: 4-20 mA (FB MIN-MAX =4-20 mA) [17]
Actual current 0-20 mA (0-IMAX = 0-20 mA) [18]
Actual current 4-20 mA (0-IMAX = 4-20 mA) [19]
Mechanical brake (MECHANICAL BRAKE) [20]
Sleep mode (SLEEP MODE) [21]
Function:
This output can act both as a digital and an
analogue output. If used as a digital output (data
value [0]-[20]), a 24 V DC signal is transmitted;
if used as an analogue output either a 0-20 mA
signal, or a 4-20 mA signal output.
Description of choice:
Unit Ready signal, the FC motor is ready for use.
Enable/no warning, the FC motor is ready for
use; no start or stop command has been given
(start/ disable). No warning.
Motor Running, the output frequency is higher than
0.1 Hz or a start command has been given.
Running no warning, the output frequency is higher than
0.1 Hz. A start command has been given. No warning.
Running on reference, no warning, speed according
to reference. No warning.
Fault, output is activated by alarm.
Fault or warning, the output is activated by
alarm or warning.
Current limit, the current limit in parameter
221 has been exceeded.
Thermal warning, above the temperature limit
in the frequency converter.
Reverse.Logic’1’ = relay activated, 24 V DC on the
output when the direction of rotation of the motor
is clockwise. Logic ’0’ = relay not activated, no
signal on the output, when the direction of rotation
of the motor is counter-clockwise.
Control word bit 11, if bit 11 = "1" in the control
word (both Fieldbus Profile and FC Profile) the
digital output will be activated.
0-fMAX (parameter 202)
⇒ 0-20 mA and
0-fMAX (parameter 202)
⇒ 4-20 mA
Reference
MIN
- Reference
MAX
:0-20mAand
Reference
MIN
- Referenc e
MAX
:4-20mA
Feedback
LOW
- Feedback
HIGH
:0-20mAand
Feedback
LOW
- Feedback
HIGH
:4-20mA
0-I
VLT, MAX
⇒ 0-20 mA and
0-I
VLT, MAX
⇒ 4-20 mA
Mechanical brake, enables control of an
optional external mechanical brake (see also
parameter 138 and 139).
Sleep m ode, active when the unit is in sleep
mode. See sectionSleep mode.
✭ = factory setting. () = display text [] = value for use in communication via serial communication port
MG.03.H3.02 - VLT is a registered Danfoss trademark
57
