Danieli Automation ID6100 User Manual

Pag. 25
Instruction Manual
EEnngglliisshh
Pag. 24
Danieli Automation - ID6100
88.. SSPPAARREE PPAARRTTSS
1122 CCoommpplleettee ppaacckkaaggee ooff
IIDD66110000 pphhoottoocceellll
DDeessccrriippttiioonn DD..AA.. ccooddee
Optical protection glass 54x34x3 mm 3985000035
Electronic card, base 5111200015
Electronic card, CCD 5111200025
Male connector, 19 terminals MIL type 3349000162
Seal for MIL connector 3349000182
Female connector, 19 terminals MIL type 3349000163
Fitting for female connector 072260PC205
Photodetector
Optical protection glass
(spare part)
Female connector, 19
terminals MIL type
Fitting for female
connector
99.. AADDDDIITTIIOONNAALL IINNFFOORRMMAATTIIOONNSS
Figure 13 indicates the physical dimensions (mm) of the photodetector.
Figure 14 shows an example of a protective housing for the ID6100 photodetector.
180
64
==
962460
48
8
22,5
R59.5
266 18
10.5
90
54
29
87
12.5
1133 IIDD66110000 PPhhyyssiiccaall
ddiimmeennssiioonnss
*DIN Reference (mm)
Side view
Front view
