Symmetric Vehicle Loading Asymmetric Vehicle Loading
FOR TECHNICAL QUESTIONS, CALL (877)432-6627
31
Fig: 33
Cylinder
bleeder
screw
STEP 19
(Operational Test Procedure)
◊ Load vehicle as per diagram below using the ALI lifting points guide
provided.
◊ Raise vehicle - 12 from the ground and check for stability.
◊
Visually inspect for leaks and r all operating components are
secure.
◊ Raise vehicle to the desired locking point and lower the lift on to the
lock and relieve hydraulic pressure.
◊ Raise the vehicle off the locks to allow clearance for the safety lock
to clear the locking block on the carriage.
◊ Vr both locks release before descending.
◊ Lower vehicle entirely until all 4 arm restraint gears are completely
released.
◊ Reference ANSI/ALI ALIS for all updated safety data.
