10AC PARTS LIST
ITEM # PART NUMBER DESCRIPTION QTY.
1 17101001 POWER SIDE POST ASSEMBLY 1
2 17101003 OFF SIDE POST ASSEMBLY 1
3 17102001 D-10 CARRIAGE ASSEMBLY 2
4 17107003 POWER SIDE SAFETY WELDMENT 1
5 17107004 OFF SIDE SAFETY WELDMENT 1
6 17204003 SAFETY CLEVIS PIN 2
7 17250001 Ø2.0 x 69 CYLINDER ASSEMBLY 2
8 17203002 2.5mm SAFETY SPRING 2
9 17108034 POWERSIDE SAFETY COVER 1
10 17108035 OFFSIDE SAFETY COVER 1
11 17108036 SAFETY SHEAVE 2
12 17300001 AB-1468 POWER UNIT 1
13 17206001 90DEG. ELBOW WITH O-RING SEAL 6801-06-06-NWO 1
14 17206002 BULKHEAD BRANCH TEE 2703-04-04-06 1
15 17206003 MALE 90DEG. ELBOW X LONG 2501-LL-04-04 2
16 17200003 M8 x 40 HEX HEAD BOLT 4
17 17200004 M10 x 30 HEX HEAD BOLT 4
18 17200005 M8 x 25 HEX HEAD BOLT 4
19 17202002 M8 LOCK WASHER 4
20 17202003 M10 LOCK WASHER 4
21 17201001 HEX NUT M8 x 1.25 8
22 17201002 M10 x 1.5 HEX NUT 4
23 17201003 9/16-18” JAM NUT 1
24 17204002 Ø3.2 HAIRPIN COTTER 2
25 17107005 LIFT HEAD PIN WELDMENT 4
26 17107006 SLIP ON LIFT PAD ASSEMBLY 4
27 17108041 SHORT LIFT PAD EXTENSION 4
28 17108042 LONG LIFT PAD EXTENSION 4
29 17106001 D-10 POWER UNIT HYDRAULIC HOSE ASSEMBLY 1
30 17106002 D-10 HYRAULIC HOSE ASSEMBLY 2299mm 1
31 17106003 D-10AC HYDRAULIC CROSSOVER HOSE ASSEMBLY 1
32 17108044 SAFETY CABLE 7166mm LG 1
33
17207007 SAFETY CABLE CRIMP 1
34 17201004 HEX NUT M12 X 1.25 2
35 17202005 M12 FLAT WASHER 2
36 17201005 M18 NYLON LOCK NUT 2
37 17202006 M18 FLAT WASHER 2
38 17104001 D-10AC TOP TROUGH ASSEMBLY 1
39 17103001 D-10AC SHORT ARM ASSEMBLY 2
40 17103002 D-10AC / ACX LONG ARM ASSEMBLY 2
41 17105002 D-10AC CABLE ASSY Ø10mm x 8794 1
42 17105001 D-10AC CABLE ASSY Ø10mm x 8870 1
43 17207009 PLASTIC COVER BLOCK 2
44 17207015 POWER UNIT VIBRATION DAMPENER 1
VISIT US ON THE WEB AT WWW.DANNMAR.COM8
