01AUG 1005GB Cat.20 / Tab. 05.91 / Page 05.03
To save the new values, press the M button for more than 3 seconds. The controller automati-
cally returns from the parameter setting mode to the parameter-selecting mode when the val-
ues are saved.
Returning to the operating mode:
Before returning to the operating mode, change from the parameter setting mode to the pa-
rameter-selecting mode as described above. To return from the parameter-selecting mode
(from any parameter) to the operating mode, press both the ∆ and the ∇ button for more than 3
seconds. If no buttons are activated, the operating mode is automatically returned to after 4
minutes (evt. new parameter limits are not saved).
Param.
No.
Text in LCD Function Ex works setting Range
00
DP-MIN
∆P –MIN
700 Pa 260-4000 Pa
01
DP-MAX
∆P – MAX
1300 Pa 280-4400 Pa
02
DP-ALARM
∆P Alarm
2300 Pa 300-5000 Pa
03
Pulse time# Puls time 60 ms 30-300ms
04
Interval time Interval time 10 4-500 s
05
DTC Interval time DT interval time 6s 2-100 s
06
Total valve no..# # of valves 0 0-160
07
DTC Down Time Cl.# Down-time cycles 6 0-32
08
DTCmax# Parameter for Down-time
Method 2
1000 280-4000 Pa
09
DTCmin# Parameter for Down-time
Method 3
260 260-2000 Pa
10
Hours in operati## Operating hours 0-250000 h
11
Text Language Languages ** Different languages are
available
12
DP-Display range Display range Pa Pa – Inch / WC
13
DTC Cleaning Mod# 3 different Down-time modes available 2 1-3
14
Test mode 0=Test off
1=Valve test
2=Start up test
3=
∆p-trimming test
4-7=test of relays and display
0 7
15
Display Contrast 68 10-200
16
Service Run Hours Service – operating hours
17
Ser. Run Hours Al. Service – operating hours – alarm 3000 h 0-25000 h
18
Ser. Run Hou. Code Service – operating hours – code ## ##
19
∆p-Mode ∆p-Mode
On On / Off
20
Setting Lock Parameters cannot be changed - Code ## ##
** Presently English, Danish, French, German.
# Locked if parameter no. 20 is ON
## Cannot be changed.
Setting of the valves on the main unit takes place in the setting mode.
