DAPAudio Compact 8.1 - Setup and Operation; Connection Cables

9
Compact 8.1
Ordercode: D2321
28. Channel 4 RCA line input connectors
Use the connectors to connect a line level device. You can select the line input with the
corresponding Mic/Line input selection (2) switch on the frontpanel.
29. Mic 4 balanced input connector
Electronically balanced combo-type input for connecting low impedance microphones. You can
select the MIC input with the corresponding Mic/Line input selection (2) switch on the frontpanel.
30. Channel 3 RCA line input connectors
Use the connectors to connect a line level device. You can select the line input with the
corresponding Mic/Line input selection (2) switch on the frontpanel.
31. Mic 3 balanced input connector
Electronically balanced combo-type input for connecting low impedance microphones. You can
select the MIC input with the corresponding Mic/Line input selection (2) switch on the frontpanel.
32. Channel 2 RCA line input connectors
Use the connectors to connect a line level device. You can select the line input with the
corresponding Mic/Line input selection (2) switch on the frontpanel.
33. Mic 2 balanced input connector
Electronically balanced combo-type input for connecting low impedance microphones. You can
select the MIC input with the corresponding Mic/Line input selection (2) switch on the frontpanel.
34. Channel 1 RCA line input connectors
Use the connectors to connect a line level device. You can select the line input with the
corresponding Mic/Line input selection (2) switch on the frontpanel.
35. Mic 1 balanced input connector
Electronically balanced combo-type input for connecting low impedance microphones. You can
select the MIC input with the corresponding Mic/Line input selection (2) switch on the frontpanel.
