DAPAudio DSA-250 User Manual

13
Product Specifications
Specification
DSA-250
DSA-400
DSA-600
DSA-800
8 Ω Stereo Power (RMS)
160W x 2
280W x 2
400W x 2
500W x 2
4 Ω Stereo Power (RMS)
250W x 2
420W x 2
600W x 2
750W x 2
8 Ω Bridge Power (RMS)
500W x 1
840W x 1
1200W x 1
1500W x 1
Frequency Response
20 Hz -20KHz: + 0.1 / - 1 dB (1W / 8 Ω)
TourClass Protection
ACL, IGM, Autoramp, DC voltage, turn-on/off transient, current inrush,
sub/ultrasonic input
THD into 4Ω, 1 KHz
<0.1%
SMPER IMD
<0.01% @8 Ω
into(50Hz &
7 Khz)
<0.01% @18 Ω
into(50Hz &
7 Khz)
<0.01% @8 Ω
into(50Hz &
7 Khz)
<0.01% @8 Ω
into(50Hz &
7 Khz)
Slew Rate
40V/ µs
40V/ µs
40V/ µs
40V/ µs
Damping Factor
300:1,1 KHz@8Ω
300:1,1 KHz@8Ω
300:1,1 KHz@8Ω
300:1,1 KHz@8Ω
Input CMRR (@1Khz)
>60dB
>60dB
>60dB
>60dB
Input Sensitivity (@8Ω)
1V for rated
power
1V for rated
power
1V for rated
power
1V for rated
power
Input Impedance
20KΩ, balanced
10KΩ, unbalanced
20KΩ, balanced
10KΩ, unbalanced
20KΩ, balanced
10KΩ, unbalanced
20KΩ, balanced
10KΩ, unbalanced
Hum and Noise
95dB
95dB
95dB
95dB
Crosstalk
>60dB
>60dB
>60dB
>60dB
Class
B
B
B
B
Input Connectors (per
channel)
Female XLR (pin 2+), TRS Combo (tip +)
Output connectors (per
channel)
Speakon connectors
Power Supply
230 V / 50 – 60 Hz
Max. Current Draw
220V
8 A
7.5 A
10.5A
15 A
Cooling
2 rear-mounted two-speed fans
Controls
2 front attenuators, power switch, signal ground lift & mode switches, filter switch
Indicators (per channel)
PROTECT LED, CLIP LED, SIGNAL LED, POWER LED
Construction
Steel chassis, 16 gauge, double thickness in rack areas
Dimensions (LxWxH)
482x360x 88 mm
Gross Weight
16.5 Kg
18 Kg
19 Kg
20.7 Kg
Net Weight
12.5 Kg
14 Kg
15 Kg
16.7 Kg
Design and product specifications are subject to change without prior notice.
Website: www.Dap-audio.nl
Email: service@highlite.nl
