DAPAudio GIG-124CFX User Manual

11
GIG-124CFX
Order code: D2285
44. PHONES
The PHONES output lets you plug in your headphones.
45. FX SEND
The FX SEND output provides the signal of the FX bus.
46. OPTIONAL MODULES SECTION
This section can be selected and installed according to the user's
requirements. Open the cover and connect the module to connector
CN6. The optional modules are: SMP-R, SMP-S, & Bluetooth-2.1.
The signal for module playback can be assigned to Main Mix by 2TK
routing. When using SMP-R recording function, the Cn12 needs to be
connected. The signal comes from the Main Mix.
