DAPAudio M10 - Panel and Cable Details; Panel Description; Connection Cables Explained

6
M10 – M12 – M15
Ordercode: D3660 – D3661 – D3662
Panel Description
Mic/line in with combo connector
Gnd switch
Switch for input sens
Link on input AC power socket
Link on XLR connector
Power LED
Clip LED indicator
lnput AC power socket
Volume control
AC fuse
EQ Presets: Monitor / FOH
Main power switch
Connection Cables
Take care of your cables, always holding them by the connectors and avoiding knots and twists when
coiling them: This gives the advantage of increasing their life and reliability.
Periodically check your cables. A great number of problems (faulty contacts, ground hum, discharges,
etc.) are caused entirely by using unsuitable or faulty cables.
Unbalanced
Balanced
