4
Section 1: ON/OFF
Press ON/OFF to activate the display. With the display on, press ON/OFF for 2 seconds to turn off power. With the
display off, there is no battery power consumption. The leakage current is no more than 2μA.
The panel will power off automatically when speed is 0km/h for 5 minutes.
Section 2: CURRENT INDICATOR
The current indicator shows the present discharging current of the controller: each segment is 2A; six segments are
>=12A.
(The bar graph shows the power output of the motor in real time. 1 bar indicates low power, full bars maximum power.)
Section 3: BACKLIGHT INDICATOR
3.1 Press ON/OFF to turn on the backlight. Press it again to turn off the backlight.
