DASHCLEAN G12 - G22 Motor Complete Assy, 230 V & 120 V

page- 28
Operating Manual G12/G18/G22/G32
2020 rev. 4.0
Part list- BD00326, Motor complete assy, 230v
POS.
Part Number
Description
Qty
1
BK00111
Nut M8
4
2
BH00082
Seal washer M8
4
3
BC00387
Filter cover
2
4
BM00287
HEPA filter
2
5
BH00110
Rubber seal
2
6
BD00360
Top cover kit
1
7
BC00388
HEPA chamber
2
8
BM00344
Motor seal
2
9
BM00160
Motor 240V 1200W
2
10
BH00023
Rubber ring
2
11
BK00035
Bolt M6x12
6
12
BM00071
Female spacer L76.5
6
13
BC00389
Motor support
2
14
BM00302
Male spacer L101.5
6
15
BK00036
Nut M6
6
16
BM00368
Foam disc adhesive
2
17
BD00358
Cover plate kit
1
18
BD00359
Chassis kit
1
19
BH00112
Rubber seal
1
20
BD00421
Electricity cord set
1
21
BM00217
Cable fix (PG11)
1
22
BD00573
Terminal block TB2505 kit
1
23
BM00406
U bypass TB2502
1
24
BD00570
Hour counter kit
1
25
BD00349
Manometer kit
1
26
BM00079
Power switch
2
27
BD00398
Wiring cable kit
1
