DASHCLEAN G12 - Page 34

page- 34
Operating Manual G12/G18/G22/G32
2020 rev. 4.0
Part list- BD00412, Motor complete assy, 240v
POS.
Part Number
Description
Qty
1
BK00111
Nut M8
6
2
BH00082
Seal washer M8
6
3
BC00387
Filter cover
3
4
BM00287
HEPA filter
3
5
BH00110
Top cover rubber seal
3
6
BD00370
Top cover kit
1
7
BC00388
HEPA chamber
3
8
BM00344
Motor seal
3
9
BM00160
Motor 230V 1200W
3
10
BH00023
Rubber ring
3
11
BK00035
Bolt M6x12
9
12
BM00071
Female spacer L76.5
9
13
BC00389
Motor support
3
14
BM00302
Male spacer L101.5
9
15
BK00036
Nut M6
9
16
BM00368
Foam disc adhesive
3
17
BD00358
Cover plate kit
1
18
BD00369
Chassis kit
1
19
BH00113
Chassis rubber seal
1
20
BD00563
Cover plate kit
1
21
BM00080
Cable fix (PG13.5)
1
22
BD00423
Electricity cord set
1
23
BD00573
Terminal block TB2505 kit
1
24
BM00406
U bypass TB2502
1
25
BD00570
Hour counter kit
1
26
BD00349
Manometer kit
1
27
BM00079
Power switch
3
28
BD00401
Wiring cable kit
1
