Page #13 background imageLoading...
Page #13 background image
SE-SR2
Operating instructions SE-SR2
826002433-EN-Rev.C
13
Inputs
Voltage at
Input circuit DC 24 V
Start circuit DC 24 V
Feedback loop DC 24 V
Current at
Input circuit DC 30 mA
Start circuit DC 60 mA
Feedback loop DC 60 mA
Max. overall cable resistance Rlmax
Dual-channel without detection of shorts across
contacts at UB DC 80 Ohm
Relay outputs
Number of output contacts
Safety contacts (N/O), instantaneous 3
Auxiliary contacts (N/C) 1
Max. short circuit current IK 1 kA
Utilisation category
In accordance with the standard EN 60947-4-1
Utilisation category of safety contacts
AC1 at 240 V
Min. current 0,01 A
Max. current 6 A
Max. power 1500 VA
DC1 at 24 V
Min. current 0,01 A
Max. current 6 A
Max. power 150 W
Utilisation category of auxiliary contacts
AC1 at 240 V
Min. current 0,01 A
Max. current 6 A
Max. power 1500 VA
DC1 at 24 V
Min. current 0,01 A
Max. current 6 A
Max. power 150 W
Utilisation category
In accordance with the standard EN 60947-5-1
Utilisation category of safety contacts
AC15 at 230 V
Max. current 3 A
DC13 (6 cycles/min) at 24 V
Max. current 4 A
