Product Reference Guide
1
Chapter 1
Introduction
About this Manual
Reference Document
[RD1]EPCglobal: EPC Radio-Frequency Identity Protocols Class-1 Genera-
tion-2 UHF RFID Protocol for Communications at 860 MHz - 960 MHz, Ver-
sion 2.0.1 (April 23, 2015).
General Information
Datalogic RFID DLR-TL001 is a low cost, semi-passive UHF Logger TAG that
allows to monitor temperature sensitive products during transportation or
storage. DLR-TL001 is compliant to the EPC Class1 Gen2/ISO18000-6C
standards, it can be used with the Gen2 UHF RFID readers on the market
without requiring any additional equipment.
Once configured using the RFID interface, the logger can be activated by a
simple manual interface that includes a button (see
Figure 1 on page 4). or
by RFID sent commands. The TAG will start to monitor the life of a tempera-
ture sensitive product allowing to identify problems occurred along the
whole cold chain in a fast and effective way.
The logger is configurable either in Continuous or Over-Threshold logging
modes and it allows to define up to 16 independent histogram bins for its
full temperature range. Each histogram permits to have different program
-
mable sampling times. Temperature logging and alarms generation can be
enabled or disabled independently for each histogram bin.
The TAG is also able to calculate the Mean Kinetic Temperature and the
remaining shelf life time and to generate alarms in case these parameters
exceed user defined thresholds.
The tag can generate alarms for the following conditions:
• "The counter of a histogram bin exceed the defined threshold
• "The Mean Kinetic Temperature value exceed the defined threshold
• "The remaining Shelf life is less than the defined threshold
• "The logging memory is full
• "The elapsed time from the start of the logging exceed the defined
Estimated Time of Arrival (ETA)
