Datalogic SR23 User Manual

142
CATALOG | Photoelectric Sensors
M8 CONNECTOR
CABLE
OPTIC FUNCTION CONNECTION OUTPUT MODEL ORDER No.
Fork Sensor
2m Cable
PNP SR23-2-IR-PH 953161000
NPN SR23-2-IR-NH 953161020
M8 Connector
PNP SR23-5-IR-PH 953161010
NPN SR23-5-IR-NH 953161030
TYPE DESCRIPTION LENGTH MODEL ORDER No.
Axial M8 Connector
4-pole, grey, P.V.C.
3 m CS-B1-02-G-03 95A251420
5 m CS-B1-02-G-05 95A251430
7 m CS-B1-02-G-07 95A251440
10 m CS-B1-02-G-10 95A251480
4-pole, P.U.R.
2 m CS-B1-02-R-02 95A251620
5 m CS-B1-02-R-05 95A251640
Radial M8 Connector
4-pole, grey, P.V.C.
3 m CS-B2-02-G-03 95A251450
5 m CS-B2-02-G-05 95A251460
7 m CS-B2-02-G-07 95A251470
10 m CS-B2-02-G-10 95A251530
4-pole, P.U.R.
2 m CS-B2-02-R-02 95A251630
5 m CS-B2-02-R-05 95A251650
INDICATORS AND SETTINGS
MODEL SELECTION AND ORDER INFORMATION
CABLES
CONNECTIONS

Datalogic SR23 Specifications

General

Brand	Datalogic
Model	SR23
Category	Security Sensors
Language	English
