Datamax H-Class Series User Manual

2
B) Press down on the Catch, then pull forward to
remove the Door.
Door
Catch
C)
Raise the Access Cover and remove your media
from the printer.
D) Remove the Thumbscrew and Tear Plate.
(Alternately, if equipped with an Arc Plate, Present
Sensor, or Peel and Present option, remove that
device.)
Tear Plate
Thumbscrew
Access
Cover
Step 2: Installing the Cutter Assembly
Carefully press the Cutter into the Front Plate
Connector and tighten the Mounting Screw to
secure the Cutter to the printer.
Cutter
Front Plate
Connector
Mounting
Screw
