Datamax H-Class Series User Manual

3
Step 3: Using the Option
During operation, cut labels will be dispensed after printing. Begin using the option as follows:
A) Load Media (see the Operator’s Manual for
details). Then, route the Media out the Cutter
Opening.
B) Plug the power cord into the AC Receptacle and
turn ‘On’ the Power Switch.
Cutter
Opening
Media
C) Ensure that READY is displayed on the Front
Panel then press the FEED Key, and proceed
according to your observations:
 If a cut label is dispensed, this completes the
installation; or,
 If the label feeds forward without being cut,
proceed to Step 4: “Configuring the Printer.”
FEED
Key
Front Panel
 Note: The operation of the Cutter can also be controlled by host software commands, so ensure
that your labeling program is properly configured for use, and for cutting labels to the desired
size.
