PRODUCT OVERVIEW
1-11
Part No. 001-4090-101/102
Setup/Diag Port
Data Format Proprietary binary for setup, ASCII for diagnostics
Data Rate 9600 b/s, 8 bit, no parity, 1 stop bit
Analog Inputs
Interface Two inputs, 0-10 VDC, 8 bits. May be read only via offline diagnostics.
Absolute maximum input voltage < 20 Vdc. Inputs are reverse-voltage protected.
Display
4 Bi-color status LEDs RUN/PWR/ CS/SYN, RX/TX, RD/TD
Connectors
RF SMA Female
COM DE-9F
SETUP/DIAG DE-9F
Power/Analog Snap & Lock 4-Pin DC Power Jack
Diagnostics
Online Short ID, temperature, B+ voltage, local RSSI, remote RSSI, fwd and rev power, Rx
Quality
Offline As for Online plus: Demodulated Signal Voltage, Analog Input Levels
