8
Zoom Button
This feature is designed for use with HD-SDI and HDMI sources above
720p resolution. Press this button to zoom in to the video on the
display. This is strictly a zooming function and does not alter the native
aspect ratio of the source pixels to fill the screen.
The ZOOM button allows you to toggle the Pixel Zoom feature
between zoom x1, x2, x4 and x8.
When turned ON the zoomed display may be moved left or right using
the VOL + /- keys and up or down using the up/down keys.
A Flashing ZOOM button light will be activated whenever you are in a
zoomed mode as a reminder/warning that the entire incoming signal is
not being shown on the monitor.
To exit zoomed mode, simply press down on the MENU key.
Volume Control Adjusts the speaker / headphone volume up / down.
Power Button
Press to turn ON / OFF the monitor.
Note: Main Power On/Off switch is located on the rear of the TLM-
170L.
Headphone Socket
3.5mm headphone socket; internal speaker circuit will automatically
mute when headphones are connected.
