1 DATECS BLUELITE V2 USER MANUAL
6
ARM Cortex® M3 Security Microcontroller
64KB Internal ROM
256KB Internal RAM
1MB Internal Flash
• ON / OFF key
• Bluetooth pairing button
• 3-track bi-directional reading
• ISO 7810, 7811 and 7813
ISO7816, EMV L1 certified
Contactless Card Reader
for payment applications
(option)
• AMEX ExpressPay
• Discover D-PAS
• MasterCard Contactless
• VISA PayWave
Contactless Card Reader
(option)
ISO/IEC 14443 Type-A/MIFARE:
- MIFARE MINI
- MIFARE CLASSIC-1K, MIFARE CLASSIC-4K
- MIFARE ULTRALIGHT, ULTRALIGHT-C
- MIFARE PLUS 2K/4K
- MIFARE DESFire
- and others
ISO/IEC 14443 Type-B
- supports most of the cards
ISO/IEC 15693
- supports most of the cards
JIS X 6319-4
- compatible with FeliCa
Rechargeable lithium-Polymer battery 3.7V, 500 mAh
• USB
- Device
• Bluetooth Low Energy 4.2
• 500 000 chip card cycles
• 1 000 000 magnetic card swipes
Dimensions (W x D x H), mm
Operating: -10
o
C to +40
o
C / 5 to 90% RH
Storage: -15
o
C to +50
o
C / 5 to 90% RH
DC 5 V, 1 A through micro USB connector
* Specification can be change without any notice.
* For actual certifications please contact to your local distributor.
Use only original equipped DATECS cable USB-A to USB-B micro
Use only UL approved USB adapters. The minimum requirements of USB
adapter is 5V/1A.
Waste Electrical & Electronic Equipment
The symbol means that according to local laws and regulations your product
shall be disposed of separately from household waste at the end of its working
life. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, please separate this from other types of wastes
and recycle it responsibly to promote the sustainable reuse of material
resources.
