32 BCS58 Master DATEQ BCS50 user manual EN
Technical information
Input Type Level Impedance Connector
AIR Unbalanced stereo -15 ... +6dBm 10 kOhm 6.3mm stereo
jack
SPARE 1 Unbalanced stereo 0dBm 10 kOhm 6.3mm stereo
jack
SPARE 2 Unbalanced stereo 0dBm 10 kOhm 6.3mm stereo
jack
TalkBack Unbalanced mono 0dBm 10 kOhm 6.3mm stereo
jack
TB control 12V, 100kOhm; switch to gnd
PGM insert L Unbalanced mono 0dBm 10 kOhm 6.3mm stereo
jack
PGM insert R Unbalanced mono 0dBm 10 kOhm 6.3mm stereo
jack
Output Type Level Impedance Connector
PGM-L Balanced left +6 dBm 600 ohm XLR-M
PGM-R Balanced right +6 dBm 600 ohm XLR-M
MONO Balanced mono
(L+R)
+6 dBm 600 ohm XLR-M
PGM-1 Unbalanced stereo 0 dBm 600 ohm 6.3mm stereo
jack
PGM-2 Unbalanced stereo 0 dBm 600 ohm 6.3mm stereo
jack
PGM-3 Unbalanced stereo 0 dBm 600 ohm 6.3mm stereo
jack
AUX Unbalanced stereo 0 dBm 600 ohm 6.3mm stereo
jack
AUD Unbalanced stereo 0 dBm 600 ohm 6.3mm stereo
jack
STUDIO Unbalanced stereo 0 dBm 600 ohm 6.3mm stereo
jack
ANNOUNCER Headphones 6.3mm stereo
jack
GUEST Headphones 6.3mm stereo
jack
C.R. Unbalanced stereo 0 dBm 600 ohm XLR-M
ON AIR 1 Control voltage 12Vdc, 1 kOhm 6.3mm stereo
jack
ON AIR 2 Control voltage 12Vdc, 1 kOhm 6.3mm stereo
jack
Ext. Meter Unbalanced stereo 0 dBm 1 kOhm SUB-D-15-F
INSERT-L Unbalanced stereo 0 dBm 600 ohm 6.3mm stereo
jack
INSERT-R Unbalanced stereo 0 dBm 600 ohm 6.3mm stereo
jack
MCA-100 Connector for the MCA-100 headphones amplifier. With this amplifier each
announcer and guest can have their own headphones with volume control
and a cough-button.
