6 Dateq LPM 7.3 Manual Connections EN
Connections
BALANCED Electronically balanced master outputs for the left and right channel on
MASTER L / R XLR connectors. This type of output guarantees a perfect signal transport
even when long audio cables are being used. These outputs are equipped
with relays to prevent audible ‘blobs’ on connected equipment when the
LPM 7.3 is switched on or off.
MASTER Unbalanced master output on cinch-connectors. Can be used to connect
the LPM 7.3 to an amplifier or a recorder.
MON Unbalanced monitor output on cinch connectors. Can be used to connect a
second amplifier with monitor speakers for the DJ or a second room.
PFL Unbalanced output on cinch connectors. This output follows the pre-fader
listening. This output can be used to connect an (monitor) amplifier or
recorder.
REC Unbalanced recorder output on cinch-connectors. This output is fixed-level
(independent from the master volume control).
EFFECT SEND Stereo postfader effect sends from microphone inputs. This output can also
be used as a cleanfeed output.
EFFECT RETURN Stereo effect return input. Can also be used as an extra input.
CHANNELS 1..7 Cinch connectors for all stereo channels. Channel 1, 2, 6 and 7 have two
identical line inputs. Channels 3, 4 and 5 have both an input for turntables
(phono) and an input for equipment like CD-players, samplers, keyboards
and recorders (line). When turntables are being used, these must be
earthen by means of the earth-clamp.
CHANNELS 1..7 Electronically balanced microphone input on XLR connector. When used
unbalanced, connect pin 1 and 3 with the shielding of the cable. Both
channels are equipped with a secondary stereo line input.
CUE Channel 3, 4 and 5 are equipped with a remote start connector. As soon as
the fader of the concerning channel is opened, the contact between tip and
ring of this mini jack (3,5 mm) connection is made. With this the connected
equipment can be remote started. The remote-connection is NOT suitable
for switching mains voltage!
FUSE Mains fuse. Dimension 5x20mm (small), 315mA slow.
MAINS Euro-style mains inlet. Before connecting the LPM 7.3for the fist time,
check if your LPM 7.3 is meant for the mains voltage in your country (label
on the connector board at the rear).
For all cinch-connectors:
White = Left, Red = Right.
