Dateq XTC Manual Technical Specifications
EN
Technical specifications
MONO INPUT
DJ MIC ............................................................XLR-3 female, electronically balanced
Signal level.............................................-54 dB @ 600 Ω variable
Impedance..............................................3 kΩ nominal
Input noise..............................................< -107 dB (IHF-A)
Headroom...............................................+20 dB
STEREO INPUTS
PHONO (X/T/C)...............................................Cinch
Signal level.............................................-42 dB @ 47 kΩ variable
Input impedance.....................................47 kΩ/ 25pF nominal
Input noise..............................................> -80 dB (IHF-A)
Channel separation ................................> 65 dB @ 1 kHz
LINE (X/T/C)....................................................Cinch
Signal level.............................................-14 dB @ 600 Ω variable
Input impedance.....................................22 kΩ nominal
Input noise..............................................> -80 dB (IHF-A)
Channel separation ................................> 65 dB @ 1 kHz
TONE CONTROL
EQUALISER MIC
Top.........................................................10 kHz ±15 dB, Shelving
Bass .......................................................80 Hz ±15 dB, Shelving
EQUALISER MIC
Top.........................................................12 kHz ±15 dB, Shelving
Mid .........................................................1400 Hz ±12 dB, Bell
Bass .......................................................50 Hz ±15 dB, Shelving
TERMINATORS
Top.........................................................-18 dB @ 12 kHz
Mid .........................................................-18 dB @ 1400 Hz
Bass .......................................................-18 dB @ 50 Hz
OUTPUTS
MASTER XLR..................................................+6 dB balanced / 600 Ω / variable
MASTER Cinch ...............................................0 dB unbalanced / 600 Ω / variable
MONITOR Cinch .............................................0 dB unbalanced / 600 Ω / variable
SUB (6,3 mm TRS Jack) .................................0 dB unbalanced / 600 Ω / < 125 Hz
PHONES (6,3 mm TRS Jack)..........................0,3 W @ 4 Ω/ Impedance 4..32 Ω
FREQUENCY RESPONSE
Mic to Master...................................................80 Hz...25 kHz -1 dB
All other inputs to Master.................................20 Hz...25 kHz -1 dB
THD + IM.........................................................0,05 % nominal
GENERAL
POWER SUPPLY
Mains voltage .........................................220...240 VAC / 50 Hz
Power consumption................................20 W
Lamp connection ....................................BNC 12 VDC / 3 W
SIZE AND WEIGHT
Front.......................................................286 x 355 mm (W x H)
Cutout.....................................................250 x 336 mm (W x H)
Depth......................................................107 mm
Weight....................................................3,9 kg Net.
