44
Transmitted Channel Messages
Status
Second
Third
Description
1000 nnnn
0kkkkkkk
0000000
Note Off.
1001 nnnn
0kkkkkkk
0vvvvvvv
Note On.
1011 nnnn
0vvvvvvv
0vvvvvvv
Control Change; see “Transmitted Controller
Messages” table following
1100 nnnn
0ppppppp
Program change, 0 – 127 for Programs 1 – 128
within current Bank
1101 nnnn
0vvvvvvv
Channel Pressure
1110 nnnn
0vvvvvvv
0vvvvvvv
Pitch Bend LS Byte then MS Byte
Notes: 0kkkkkkk Note number 0 - 127
nnnn Channel number 0 to 15 (MIDI channel 1-16). Ignored if MIDI
channel set to ALL
0vvvvvvv Value
Transmitted Controller Messages
Status
Second
Third
Description
1011 nnnn
0000 0001
0vvvvvvv
Mod Wheel
1011 nnnn
0000 0010
0vvvvvvv
Breath Controller – when assigned to Pedal/CV
1011 nnnn
0000 0100
0vvvvvvv
Foot Controller – when assigned to Pedal/CV
1011 nnnn
0000 0111
0vvvvvvv
Volume – when assigned to Pedal/CV
1011 nnnn
0100 1010
0vvvvvvv
Brightness – when assigned to Pedal/CV
1011 nnnn
0000 1101
0vvvvvvv
Expression – when assigned to Pedal/CV
1011 nnnn
0010 0000
0vvvvvvv
Bank Select – 0 to 7
1011 nnnn
0100 0000
0vvvvvvv
Damper pedal – sends 0 if off, 0100 0000 when
on
1011 nnnn
0000 0111
0vvvvvvv
Volume knob
See sections below for additional Continuous Controller (CC) and Non-
registered Parameter Number (NRPN) messages transmitted.
