Dave Smith Instruments Mopho x4 - Parameter Data

43
MIDI Messages
System Real-time Messages
Status
Description
1111 1000
MIDI Timing Clock
Received Channel Messages
Status
Second
Third
Description
1000 nnnn
0kkkkkkk
0vvvvvvv
Note Off. Velocity is ignored
1001 nnnn
0kkkkkkk
0vvvvvvv
Note On. Note off if vvvvvvv = 0
1010 nnnn
0kkkkkkk
0vvvvvvv
Polyphonic Key Pressure
1011 nnnn
0vvvvvvv
0vvvvvvv
Control Change; see “Received Controller
Messages” table following
1100 nnnn
0ppppppp
Program change, 0-127 for Programs 1-128
within current Bank
1101 nnnn
0vvvvvvv
Channel Pressure
1110 nnnn
0vvvvvvv
0vvvvvvv
Pitch Bend LS Byte then MS Byte
Notes: 0kkkkkkk Note number 0 — 127
nnnn Channel number 0 to 15 (MIDI channel 1-16). Ignored if MIDI
channel set to ALL
0vvvvvvv Value
Received Controller Messages
Status
Second
Third
Description
1011 nnnn
1
0vvvvvvv
Mod Wheel — directly assignable controller
1011 nnnn
2
0vvvvvvv
Breath Controller — directly assignable controller
1011 nnnn
4
0vvvvvvv
Foot Controller — directly assignable controller
1011 nnnn
7
0vvvvvvv
Volume — Combined with Master Volume and
Voice Volume
1011 nnnn
74
0vvvvvvv
Brightness — Added to low-pass filter cutoff
frequency
1011 nnnn
11
0vvvvvvv
Expression Controller — directly assignable
controller
1011 nnnn
32
0vvvvvvv
Bank Select — 0 - 3 select user banks 1 - 4; 4 - 7
select factory banks 1 - 4; others ignored
1011 nnnn
64
0vvvvvvv
Damper pedal — holds envelopes in Sustain if
0100 0000 or higher
1011 nnnn
123
0vvvvvvv
All Notes Off — clear all MIDI notes
1011 nnnn
121
0vvvvvvv
Reset All Controllers — clears all MIDI
controllers to 0, MIDI volume to maximum
See sections below for additional Continuous Controller (CC) and Non-
registered Parameter Number (NRPN) messages received.
