Dave Smith Instruments Mopho x4 - Global Parameter Data

47
Received NRPN Messages
Status
Second
Third
Description
1011 nnnn
0110 0011
0vvvvvvv
NRPN parameter number MSB CC
1011 nnnn
0110 0010
0vvvvvvv
NRPN parameter number LSB CC
1011 nnnn
0000 0110
0vvvvvvv
NRPN parameter value MSB CC
1011 nnnn
0010 0110
0vvvvvvv
NRPN parameter value LSB CC
1011 nnnn
0110 0000
0xxxxxxx
NRPN parameter value Increment
1011 nnnn
0110 0001
0xxxxxxx
NRPN parameter value Decrement
1011 nnnn
0010 0101
0111111
RPN parameter number MSB CC - Reset NRPN
parameter number (when both MSB and LSB
received)
1011 nnnn
0010 0100
0111111
RPN parameter number LSB CC - Reset NRPN
parameter number (when both MSB and LSB
received)
Global Parameter Data
The following table shows the Global data that is sent and received on global
parameter dumps, and the corresponding NRPN number when sent/received
individually.
Param
NRPN
Range
Description
0
384
0 - 24
Master Transpose; 0 = -12 semitones (1 octave), 12
= 0 (no transpose), and 24 = +12 semitones.
1
385
0 - 100
Master Fine Tune; 0 = -50 cents, 50 = 0 (centered),
100 = + 50 cents
2
386
0 - 16
MIDI Channel; if = 0, data received on all MIDI
channels. Otherwise = channel number 1 - 16.
3
388
0 - 3
MIDI clock select*
0 Use Internal clock, don’t send MIDI clock
1 Use Internal clock, send MIDI clock
2 Use MIDI clock In
3 Use MIDI clock In, and retransmit MIDI clock out
4
390
0 - 2
Parameter Send*:
0 NRPN
1 CC
2 Off
5
391
0 - 3
Parameter Receive†:
0 All
1 NRPN only
2 CC only
3 Off
6
394
0 - 1
MIDI Controller Send/Receive Off/On
7
395
0 - 1
MIDI Sysex Send/Receive Off/On
