INSTALLING YOUR MICROLENE® QUICK CONNECT
UNDERBENCH SYSTEM
Step One: INSTALLING THE TAP
• Determine the most suitable location on your bench top for mounting
the tap. If your bench top is Marble, Granite or Concrete, do not attempt
to drill these materials yourself as these surfaces are easily damaged.
Instead contact your nearest Kitchen Supplier for advice on a trade
professional to drill the hole for you.
• Drill a 13mm (1/2”) hole in your preferred location on the bench top (most
people prefer a rear corner of the sink).
• Remove the locking nut and washers from the stem of the tap, place the
tap at the desired angle on the top of the bench and then with a spanner
rmly connect the locking nut and washers to the stem of tap under
the bench. The tap should now be xed to your bench top and held in
position.
• Unscrew the top of the tap and push the spout into place using enough
force to ensure the orings on the spout are in place. Place the locking
nut over the spout and screw back into place.
• Screw a push lock tting (female thread) on the threaded end of the tap
under the bench
Step 2: CONNECTING TO YOUR COLD WATER LINE
• Turn o the water supply to the house
• Locate the cold water line under the sink. If your cold water line is either
copper or plastic pipe; you will need to purchase a C-Clamp Kit.
If your cold water line is a exi hose only use the Pipe Tap Kit.
Unscrew the exi hose at the house tap end, screw the main body of the
pipe tap adaptor into the house tap, and then screw the exi hose onto
the threaded end of the pipe tap adaptor.
Screw the smaller outlet tap from the Pipe Tap kit into the female
threaded port on the main body of pipe tap adaptor. Finally screw a push
lock tting onto the male threaded out port of the smaller outlet tap.
WARNING : Microlene
®
underbench system installation must be in compliance
with all local legislative requirements. Please note that C-Clamp kit may not be
accepted in certain markets.
