3. PARTS DESCRIPTION
Fig. 1A
1. Throttle choke Lever 2. Rope guide 3. Locking Lever 4. Grass catcher
5. Height adjusting lever 6. Deck 7. Sideward flap 8. Front cover
9. Spark Plug 10. Fuel cap 11. Oil Cap 12. Starter handle
13. Self-drive control handle 14. Brake control handle 15. Upper handle 16. Side discharge chute
17. Mulching wedge
Including A: Spark plug wrench
4. TECHNICAL DATA
Model M51SPC (DYM1660AQ)
Engine type DG600
Self Propelled Yes
Engine Displacement 173 cm
3
Blade Width 510 mm
Speed at max. Power 2800/min
Fuel Tank Capacity 2.0L
Grass catcher capacity 60 L
Net Weight 37.3 kg
Height adjustment : 25-75mm, 10 adjustment
M51SPC
Guaranteed Sound pressure level
at the operator’s position
(According to EN 836 Annex H&
EN ISO 4871)
84.3dB(A)(K=3dB(A)
