ASSEMBLY
We recommend a 2-person assembly for this product.
1. Open legs to the standing position.
Caution: Beware of pinch points when opening or closing the clothesline
SLIDE LOCK
LEG CLIP
STEP 1. Stand frame on its end to
open the outer pair of legs.
STEP 3. Slowly rotate the legs
to the open position and rest on
the ground. Note: the legs will
automatically open as they rotate
outwards.
STEP 2. To release the legs, carefully spread open the leg clip
whilst pulling outwards on the legs.
Gently push up on the hinge to
ensure it locks into place (click
sound).
STEP 4. The legs are fully open
when the metal hinge is aligned
and locked into the slider clip.
STEP 5. Repeat at other end. Carefully spread open the leg clip to release
the legs. Note: Be careful to support the legs as they are released and open.
3
