LINE START 2
LINE END 2
Important: Tension lines with light hand pull
LINE START 1
ASSEMBLY (CONTINUED)
3. Thread the clothesline cord.
2. Attach arms to frame
STEP 2. Once fully threaded pull the cord
reasonably tight to ensure there are no
loose sections.
STEP 1. Thread the cord on both sides of the
clothesline as shown below. Start at the inner most
hole and work your way through to the outside hole
and through the line tensioner.
STEP 1. Take 1 arm assembly and
slot into position as shown below.
SPRING BUTTON
STEP 2. The arm will lock into place
and be held by the spring button.
STEP 3. Repeat this process for the
other arm.
4
