Raider Max 250(single/double-seat) : Owner’s Manual Version:1.0 Oct. 2005

SPECIFICATIONS

DIMENSIONS SINGLE-SEAT/DOUBLE-SEAT

Overall Length 2410mm / 2270mm

Overall Width 1310mm / 1610mm

Overall Height 1425mm /1533mm

Wheelbase 1555mm /1700mm

Ground Clearance 200mm / 250mm

VIN accord with GMVR A01-01

Statutory Plate& Safety Labels accord with GB 7258-1997

ENGINE

Model PMI172MM

Type Forced Water-cooled, Single Cylinder, 4-stroke

Engine Capacity 250cc

Displacement 244.3ml

Bore×Stroke 72mm×60mm

Max. Power 12.5kw or 6500rpm
