B-HYPE 8 - B-HYPE 10 - B-HYPE 12 - B-HYPE 15 Cod. 420120254 REV. 1.0
CONNECTING THE OUTPUT OF MULTIPLE MODULES (audio daisy chain)
For the input connection
of a microphone, select
"MIC" position of "Input
Audio Sensitivity" selector.
It is possible to use a
cable with both XLR and
TRS male connector.
For the audio daisy chain to
a second B-HYPE speaker,
use a cable with XLR male-
female connector. Insert the
female connector into the
"Balanced Link" output of
the rst speaker, and the
male connector into the
"Balanced Input" of the
second speaker. It is necessary
to select the "LINE" position
of "Audio Input Sensitivity"
on the second B-HYPE.
Please nd some examples of
connections in the next page.
MICROPHONE
English
