Hookup
Peak Led
(it indicates when the limiter works)
OLED Display
Rotary Encoder with switch
Use the encoder to navigate between menus and click to confirm/select
Mic/Instrument input
XLR combo input allows to connect microphone or instrument
Ch./Ch. line inputs
XLR combo line input
Aux/Mix Output
XLR output connector ( balanced signal output enabled for monitoring or link to another speaker)
USB port
Use this port only for upgrade (see Usb Burner Manager)
