dB-technologies’s products are fully compliant with the relevant Standard Regulations. In most countries,
nevertheless, wireless systems must be approved for use by the Authorities and may be necessary to obtain a licence
to use it legally. Your local dealer will be able to give you details on wireless system regulations for your area.
19
IEM2200 Technical Specification
Transmitter
Transmitter size: Rack-mounting (19”), 1 u (1.75”), 9” deep (max.)
Transitter weight: 2 Kg approx./4.5 1bs
Power input: 12 Volts a.c. @ 250mA 50/60 Hz
Inputs: Electronically balanced, Neutrik Combo™ XLR
connectors (pin 2=hot, pin 3=cold)
Link outputs: 6.3mm ( ¼”) jack sockets (tip=hot, ring= cold)
Sensitivity: 0 dBV / 600 Ohms nominal
Frequency response: 50 Hz to 15kHz ± 3dB
Distortion: <1%
Level control: Dual adjustment for individual control over left & right
inputs
Metering: Input level bargraph display for each channel.
Monitor output: 6.3mm and 3.5mm stereo jack sockets and stereo volume control, 25
Operating frequency: 16 pre-programmed frequencies*
RF output power: 25mW e.r.p. as measured in accordance with ETS300 422
Modulation: frequency modulation ± 35KHz nominal deviation
dynamics control: Variable ratio compressor
Antenna: ¼ wave ship
Temperature range: -10°C to +50°C
