Receiver
Power: 9V alkaline battery
Battery life: 6,5 to 8 hours depending upon volume
Earpiece output: 250 mW / 16 Ohms per channel
Distortion: <1%
Channel separation: 40dB @ 1kHz typical
Frequency response 30 Hz to 15kHz ~ 3dB
Signal to noise ratio 105dB typical measured in mono mode
100dB typical measured in stereo mode
Sensitivity < 2uV for 20dB SINAD
Operating frequency: 16 pre-programmed frequencies*
Antenna: Integral ¼ wave whip
Low battery warning: a flashing indication on the LCD panel alert the user to replace t
Muting: Soft mute circuits ensure no loud pops or other noises in low RF
situations. Silent shutdown in the event of loss of RF.
System
Frequency response: 50 Hz to 15 kHz ± 3dB
THD + Noise: < 1.0%
Signal to noise: > 100dB nominal
Compliance: ETS 300 422 & ETS 300 445
